Description

Evapco PMCB 1770 Evaporative Condenser (1770 Package Nominal Tons,1-30 HP Motor, 2 Tower Units)
Year of Manufacture: 1997
Number Units in Package: 2 unit (2 top sections and 1 common bottom that cannot be separated)
Nominal Tons (total): 1770 TR*
Ammonia Tons (total): 1255 TR*

Nominal Tons (per unit): 885 TR*
Ammonia Tons (per unit): 627.5 TR*

R-717 (ammonia) or R22 (freon). Last run with Ammonia.
Design pressure: 350 PSIG
Pump Requirements (per unit): 2x 7.5 pump motors at 460V, 60 Hz, 3 phase
Pump Included? No, can purchase separately
Fan Details (per unit): (6) fans. (2) 30 hp and (2) 15 hp fan motors at 460V, 60 Hz, 3 phase

Top Dimensions (per unit): 19’6 L x 12′ W x 7’2 H (2 top sections)
Top Weight (per unit): 26,560 LBS (2 top sections)
Bottom Dimensions (per unit): 39’L x 12’W x 8’7H (one full bottom section, cannot be separated)
Bottom Weight (per unit): 17,190 LBS (one full bottom section, cannot be separated)

Other Notes about machine: (2) Hansen Technologies hand valves, (2) Henry Technologies hand valves, (4) Hansen Technologies Pressure relief valves Cat. No. H5602. (2) manways, 20 in. diameter. Inlet / outlets: (2) 2 in. threaded, (1) 3 in threaded, (1) 3-1/2 in. threaded, (2) 6 in., (8) 4 in. (ACN2066)

*Tons at standard conditions: 96.3°F condensing, 20°F suction and 78°F Wet Bulb

Can sell one tower unit from a group upon request for a fee. Please request as needed.
