Description

Hougen 12252 1-5/8in. x 2in. in.12

 Hougen 12252 1-5/8″ x 2″ “12,000-Series” Annular Cutter, New Surplus

Ready to ship    Next Business Day

Item Details

For use with Hougen® Portable Magnetic Drills and many competitive models on materials up to 275 BHN (28.5 HRC). They are made of hardened M2 high speed steel and are precision ground for excellent performance throughout the cut and long tool life. They require less horsepower and thrust to cut, and last much longer than traditional holemaking methods.”12,000-Series” cutters have a 3/4″ diameter double-flatted shank. Modified end tooth geometry is also available for drilling in stacked plate applications. For extended tool life and lower cost per hole “12,000-Series” Cutters are resharpenable.

Benefits

Makes large diameter holes efficiently without the mess of chips

Hole produces a slug of material that could be used for another job

Features

Hardened M2 high speed steel material

Precision ground & fully fluted provides better chip evacuation, requires less horsepower & offers better performance in deeper holes

3/4″ double flatted shank is very rigid & offers up to 2 times the tool life as compared to quick change tool mounting on competitive products

Only a thin area of material touches the outside of the hole which provides for less friction and a better hole finish

Patented hougen-edge geometry provides faster, smoother cuts, with less chatter

Tapered inner diameter provides a relief area between the slug & cutter to reduce horsepower & improve slug ejection

Up to 10 cutting edges distribute the cutting load evenly to maximize feed rates

The slug offers a higher scrap value than loose chips
