Infinity Bond 161-224 Disposable Static Mixer Nozzle
Infinity Bond 161-224 Static Mixer Nozzle Overview
The Infinity Bond 161-224 is a direct cross to the Nordson 7701010 (TAH 161-224) made in the USA using super high quality materials. This static mixer uses a standard bell attachment and comes with a stepped tip that can be cut to adjust the diameter of adhesive bead being dispensed.
The 161-224 static mixer has a bell connection that requires a retaining nut to connect and is best used with larger cartridges (200, 400 or 600mil) or meter mix equipment. This static mixer is for 1:1 or 2:1 adhesives and uses 24 elements for mixing.
Works Great with:
Epoxy
Polyurethane
Silicone
Methyl Methacrylate
Replaces These Name Brand Mixers
Nordson 7701010
TAH 161-224
Additional Information
Works with: 200mL, 400mL, 600mL cartridges
Bell housing connection: 0.657 in/18.7mm
Mix ratios: 1:1, 2:1
Retaining nut: 7/8-9 thread or 7/8-14 thread
Casing: Polypropylene
Element: High strength Polyacetal
Infinity Bond 161-224 Static Mix Nozzle Specifications
