Sisma SWT 150 F Laser Welder (Closed)

The SWT fiber laser welders are available in 2 configurations: Class 1 (closed) or Class 4 (open). Choose what works best for your shop! The SWT is specifically designed for the maintenance of medium to small sized molds up to 15.75″ square (400mm). The robust design and sturdy working platform gives the operator outstanding comfort and minimal vibration. Controlled via joystick, the working platform moves up or down on the Z-axis with a range of 12.5″ (320mm). The X and Y-axis movements are 11.75″ and 7.75″ respectively (300 x 200mm).

The ergonomic design of the SWT Class 1 (closed) is ideal for prolonged use. Soft armrests, adjustable doors, and adjustable footboard create a comfortable working environment. The stable working platform, on both Class 1 and Class 4 models, minimizes any vibrations, even at the full load capacity of 264 lbs. (120kg). Fiber laser welders offer the highest productivity and efficiency when it comes to processing speeds.  They are maintenance-free and with the advantage of having zero downtime.

Made in Italy. Backed by a 1-year manufacturer’s warranty. Installation, training, and service provided by Gesswein Company.


Key Features:

  • Available Open or Closed Configuration
  • Medium to Small Size Molds
  • Pulse shaping software for easy tuning to eliminate porosity, undercut, or sink.
  • Programmable Path Settings –Overlap, Line, Radius, Oblique, Fill, Rotating Spindle and More
  • Motorized Control of X, Y, and Z Axes (via Joystick)
  • Attach a 4th axis for circumferential welding.
  • Internet Connection for Remote Service Management and Free Upgrades

Model

SWT 150F

SWT 300F

SWT 450F

Item # Class 1

833-1876

833-1878

833-1880

Item # Class 4

833-1870

833-1872

833-1874

Source Type

Fiber

Fiber

Fiber

Wavelength

1070 nm

1070 nm

1070 nm

Average Laser Power

150W

300W

450W

Max Peak Power

1.5kW

3.5kW

4.5kW

Max Pulse Energy

15J

30J

45J

Pulse Frequency

0 – 50 Hz

0 – 50 Hz

0 – 50 Hz

Pulse Duration

0.3 ms – 10 ms

0.3 ms – 10 ms

0.3 ms – 10 ms

Laser Spot Diameter

0.1mm – 2mm

0.1mm – 2mm

0.1mm – 2mm

Axis Speed

0.1mm/s – 25 mm/s

0.1mm/s – 25 mm/s

0.1mm/s – 25 mm/s

X Axis Stroke

11.8″ (300mm)

11.8″ (300mm)

11.8″ (300mm)

Y Axis Stroke

7.9″ (200mm)

7.9″ (200mm)

7.9″ (200mm)

Z Axis Stroke

12.6″ (320mm)

12.6″ (320mm)

12.6″ (320mm)

Cooling

–

–

–

Max Load Weight

264 lbs. (120kg)

264 lbs. (120kg)

264 lbs. (120kg)

Max Mold Size
(L x W x H)

15.7″ x 15.7″ x 12.6″ (400mm
x 400mm x 320mm)

15.7″ x 15.7″ x 12.6″ (400mm
x 400mm x 320mm)

15.7″ x 15.7″ x 12.6″ (400mm
x 400mm x 320mm)

Power Supply

230V±10%, 1Ph, 1.6kW

230V±10%, 1Ph, 2.2kW

230V±10%, 1Ph, 2.8kW

Dimensions (L x W x H)

33″ x 48″ x 60″ (850 x 1200 x
1500mm)

33″ x 48″ x 60″ (850 x 1200 x
1500mm)

33″ x 48″ x 60″ (850 x 1200 x
1500mm)

Weight

1,235 lbs. (560kg)

1,235 lbs. (560kg)

1,235 lbs. (560kg)



Established in 1961, Sisma is a worldwide recognized name for the design and production of extremely high precision laser machinery. Suiting the needs of diverse industries; jewelry, machining, prototyping, dental, and medical, Sisma’s expansive line of customizable laser solutions are synonymous with quality and superiority. Innovative by vocation, Sisma combines technologically advanced machines with unique patents. When coupled with a world class service and support network, optimal efficiency and utilization of their products are guaranteed.
