ULTRAMAX® DF POWER SET – 1/8″

The ULTRAMAX® DF Power is a dual-function
system that gives you the versatility of both ultrasonic and mechanical
polishing. Achieve mirror finishes on milled and EDM surfaces using the
ULTRAMAX® DF Power with finishing stones, files, ceramic stones, lapping stones
with diamond compounds, and sintered, resin, and plated diamond tools. With a
maximum output of 100 Watts, you can even polish the toughest metals like
titanium and tungsten carbide with ease.

The ULTRAMAX® DF Power comes with a UF-9705
ultrasonic handpiece (6mm thread), a PHP35 rotary handpiece (1/8″ collet), and its DC motor port is
compatible with the entire line of Gesswein Power Hand® micromotor system handpieces. For
the toughest jobs, turn to the optional UF-7405 handpiece with 8mm thread which is ideal if you have very heavy-duty EDM applications (see our 5001322 – sold separately).

Short stroke length and fast reciprocation
give you total control over the most difficult polishing and deburring tasks.
Polish right up to walls and deburr edges with the system’s special control
functions. Use the NANO function for delicate, ultra-fine polishing and the
TOUCH function to protect your workpiece from accidental contact.

ULTRAMAX® DF Power Functions

• NANO Function – The
  normal stroke length of the DF Power is adjustable between 3-40μm. With
  NANO mode, you can reduce the adjustable stroke length to a minute 1-3μm
  range. This is ideal for ultra-high polishing such as diamond compound
  polishing or when you need to remove a very small amount of metal.
• TOUCH Function – When
  the TOUCH function is activated, the mounted tool in your ultrasonic
  handpiece will reciprocate at full power only when contact is made with
  the metal surface of your workpiece. When you remove the tool from the
  metal surface, the reciprocation reduces to minimum power to protect your
  workpiece from any accidental contact.
• FINE Function – Allows you to fine-tune the output.  The unit will normally save you time by jumping in increments of 5’s but switching to the FINE Function allows you to further set the output to the exact whole number you require.
